KNURLING ROLL HOLDERS FOR KNURLING BY DEFORMATION - HOLDERS ARE ADJUSTABLE
55105116, 55105117
Description
Specification
TWO KNURLING ROLLS SET UP SHOWN
CROSS30° KNURL
USE MRRV-30°
MRLV-30°
1EACH
SINGLE KNURLING ROLLS SET UP SHOWN
STRAIGHT KNURL (00°)
USE MRSV-00° 1PC
UNIT: mm
| ITEM NO. | MODEL | DIMENSIONS | ROLLS SPEC. | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| H x B | G | C | L | E | K | |||||
| 55105116 | PSHMR-2066 | 20 x 20 | 3.3 | 29 | 125 | 32 | 6.5 | 20 | 6 | 6 |
| 55105117 | PSHMR-2566 | 25 x 25 | 3.3 | 32 | 140 | 32 | 6.5 | 20 | 6 | 6 |
